Adapter cable 4pF>ECU Uni

Adapter cable 4pF>ECU Uni

Logg inn for å se priser

SKU 312244 Category

Description

Adaptercable Volvo ECU – Uni

Adaptercable Volvo ECU – Uni is a specially designed cable for connection to Volvo ECU systems. The cable combines coaxial cable for video signal, power cables and data cable in one unit, simplifying installation and reducing cable clutter. It is designed to deliver reliable performance in demanding environments.

The cable is manufactured with high-quality materials, including tinned copper and a robust TPE-U jacket. This ensures good signal integrity, durability and resistance to extreme temperatures. It is suitable for use in a wide range of applications that require a robust and reliable connection.

Properties for Adaptercable Volvo ECU – Uni

  • Cable: Multicable 1x coax, 2x pwr, 1x data
  • Coaxial shielding: Tinned copper, braided ≥85%.
  • Coaxial cable: 26AWG 19 x 0.10 mm, core: CU-ETP1 according to DIN EN 13602, shield tinned copper braided ≥85%, sheath PP.
  • Conductors (C1 to C3): 3 x AWG22, 7 x 0.25mm, tinned copper, colors: black, red, orange.
  • Cover: TPE-U Sh A 85 +/-5, halogen-free, diameter 6mm +0.0/-0.2mm, color: black RAL 9005.
  • Temperature range: -40°C to +85°C
  • Minimum bending radius: 7.5 x diameter (static)
  • Coaxial impedance: 75Ω
  • Connector: 4-pin female IP67 gold
  • Weight: 0.040kg

Adaptercable Volvo ECU – Uni is a reliable and robust cable designed to ensure optimal performance and connectivity in Volvo ECU systems, even under demanding operating conditions.
